TurtleBot3

Turtlebot3

TurtleBot3_Video

The TurtleBot3 is a popular educational and research robot platform developed by ROBOTIS in collaboration with Open Robotics. It's widely used for learning robotics, SLAM, navigation, and autonomous systems development.

System Overview

TurtleBot3 is a compact, affordable, and highly customizable mobile robot designed for education, research, and hobby applications. It features a modular design that supports various sensor configurations and computing platforms.

Key Features

  • Compact Design: Small footprint ideal for indoor navigation
  • Modular Architecture: Customizable sensor and hardware configuration
  • ROS Native: Full ROS/ROS2 integration and support
  • Educational Focus: Extensive documentation and learning resources
  • Open Source: Hardware and software designs freely available
  • Multiple Variants: Burger, Waffle, and Waffle Pi configurations

Specifications

  • Dimensions: Approximately 178mm × 178mm × 192mm (Burger model)
  • Weight: ~1kg (varies by model and configuration)
  • Max Speed: ~0.22 m/s linear, ~2.84 rad/s angular
  • Battery Life: ~2.5 hours (varies by usage)
  • Wheel Configuration: 2-wheel differential drive
  • Computing: Raspberry Pi or similar SBC

Components

Drive System

  • Motors: Two servo motors (Dynamixel XL430-W250-T)
  • Wheels: Two main drive wheels with omni-directional caster wheel
  • Encoders: Built-in position feedback in Dynamixel servos
  • Drive Type: Differential drive kinematics

Standard Sensors

  • LiDAR: 360-degree laser range finder (LDS-01 or LDS-02)
  • IMU: 9-axis inertial measurement unit
  • Odometry: Wheel encoder-based position estimation
  • Optional: Camera (RealSense, Raspberry Pi camera)

Computing Platform

  • Single Board Computer: Raspberry Pi 3B+ or 4
  • Microcontroller: OpenCR board for low-level control
  • Communication: Wi-Fi, Ethernet, Serial interfaces

Available Functions

The TurtleBot3 example includes comprehensive MATLAB functions for Simulink integration:

  • wb_robot_step.m - Main simulation step function
  • wb_motor_set_velocity.m - Differential drive velocity control
  • wb_motor_set_position.m - Motor position control
  • wb_motor_get_position_sensor.m - Wheel encoder readings
  • wb_gyro_get_values.m - IMU gyroscope data
  • wb_accelerometer_get_values.m - IMU accelerometer data
  • wb_lidar_get_range_image.m - LiDAR scan data processing
  • wb_lidar_get_horizontal_resolution.m - LiDAR configuration

State-Space Modeling

The included Simulink model (state_space_modeling.slx) provides:

  • Differential Drive Kinematics: Forward and inverse kinematic models
  • Sensor Fusion: IMU and odometry integration
  • Navigation Control: Velocity and trajectory control
  • SLAM Integration: Real-time mapping capabilities
  • Obstacle Avoidance: LiDAR-based collision avoidance

Control System Design

Differential Drive Kinematics

The TurtleBot3 uses differential drive kinematics where linear and angular velocities are controlled through left and right wheel speeds:

% Forward kinematics
v = (v_left + v_right) / 2;      % Linear velocity
w = (v_right - v_left) / L;      % Angular velocity

% Inverse kinematics
v_left = v - (w * L) / 2;        % Left wheel velocity
v_right = v + (w * L) / 2;       % Right wheel velocity

Where: - v: Linear velocity (m/s) - w: Angular velocity (rad/s) - L: Wheelbase distance (m)

Control Architecture

  1. Low-level Control: Motor velocity control with PID feedback
  2. Motion Control: Velocity and trajectory following
  3. Navigation: Path planning and execution
  4. SLAM: Simultaneous localization and mapping
  5. Behavior: Task-level behavior coordination

System Block Diagram

flowchart TB
    subgraph Reference["Reference Inputs"]
        R1[/"Goal Position<br/>(x_g, y_g)"/]
        R2[/"Velocity Command<br/>(v, ω)"/]
    end

    subgraph Navigation["Navigation Stack"]
        SLAM[SLAM<br/>Module]
        GP[Global<br/>Planner]
        LP[Local<br/>Planner]
        AMCL[AMCL<br/>Localization]
    end

    subgraph Perception["Perception"]
        LIDAR[LiDAR<br/>LDS-01]
        IMU[IMU<br/>9-Axis]
        ODOM[Wheel<br/>Odometry]
    end

    subgraph Control["Motion Control"]
        subgraph VelCtrl["Velocity Controller"]
            VC[Twist to<br/>Wheel Velocity]
        end
        subgraph MotorCtrl["Motor Controller"]
            PID_L[PID<br/>Left]
            PID_R[PID<br/>Right]
        end
    end

    subgraph Actuators["Drive System"]
        ML[Left<br/>Dynamixel]
        MR[Right<br/>Dynamixel]
    end

    subgraph Plant["TurtleBot3"]
        ROBOT[Robot<br/>Dynamics]
    end

    R1 --> GP
    GP --> LP
    LP --> VC
    R2 --> VC

    LIDAR --> SLAM
    LIDAR --> LP
    ODOM --> SLAM
    ODOM --> AMCL
    IMU --> AMCL
    SLAM --> GP
    AMCL --> LP

    VC --> PID_L
    VC --> PID_R
    PID_L --> ML
    PID_R --> MR

    ML --> ROBOT
    MR --> ROBOT

    ROBOT --> LIDAR
    ROBOT --> IMU
    ROBOT --> ODOM

    style Reference fill:#e1f5fe
    style Navigation fill:#fff3e0
    style Perception fill:#f3e5f5
    style Control fill:#e8f5e9
    style Actuators fill:#ffebee
    style Plant fill:#fce4ec

State-Space Model

flowchart LR
    subgraph Inputs["Control Inputs u"]
        U1["v (Linear Velocity)"]
        U2["ω (Angular Velocity)"]
    end

    subgraph StateSpace["State-Space Model<br/>ẋ = f(x,u)"]
        subgraph States["State Vector x"]
            S1["x - X Position [m]"]
            S2["y - Y Position [m]"]
            S3["θ - Heading [rad]"]
        end
    end

    subgraph Outputs["Outputs y"]
        Y1["Position (x, y)"]
        Y2["Orientation (θ)"]
    end

    Inputs --> StateSpace
    StateSpace --> Outputs

    style Inputs fill:#ffcdd2
    style StateSpace fill:#c8e6c9
    style Outputs fill:#bbdefb

Differential Drive Model

flowchart TB
    subgraph DiffDrive["Differential Drive Kinematics"]
        subgraph Forward["Forward Kinematics"]
            F1["ẋ = v·cos(θ)"]
            F2["ẏ = v·sin(θ)"]
            F3["θ̇ = ω"]
        end

        subgraph WheelVel["Wheel-Body Velocity"]
            W1["v = r(ω_R + ω_L)/2"]
            W2["ω = r(ω_R - ω_L)/L"]
        end

        subgraph Inverse["Inverse Kinematics"]
            I1["ω_L = (v - ωL/2)/r"]
            I2["ω_R = (v + ωL/2)/r"]
        end
    end

    subgraph Params["TurtleBot3 Parameters"]
        P1["r = 0.033 m (wheel radius)"]
        P2["L = 0.160 m (wheelbase)"]
        P3["v_max = 0.22 m/s"]
        P4["ω_max = 2.84 rad/s"]
    end

    Forward --> WheelVel
    WheelVel --> Inverse

    style DiffDrive fill:#e8f5e9
    style Params fill:#fff8e1

State-Space Matrices

%% TurtleBot3 State-Space Model
% Nonlinear kinematic model (differential drive)
% State vector: x = [x, y, theta]'
% Input vector: u = [v, omega]'

% TurtleBot3 Burger Parameters
r = 0.033;        % Wheel radius [m]
L = 0.160;        % Wheelbase (wheel separation) [m]
v_max = 0.22;     % Maximum linear velocity [m/s]
omega_max = 2.84; % Maximum angular velocity [rad/s]

% Nonlinear dynamics (for simulation)
% dx/dt = v * cos(theta)
% dy/dt = v * sin(theta)
% dtheta/dt = omega

% Linearized model around operating point (theta_0)
% For small deviations from straight-line motion

theta_0 = 0;  % Operating point heading

A = [0, 0, 0;
     0, 0, 0;
     0, 0, 0];

B = [cos(theta_0), 0;
     sin(theta_0), 0;
     0, 1];

C = eye(3);
D = zeros(3, 2);

% Extended state-space with velocity dynamics
% State: [x, y, theta, v, omega]'
% Input: [v_cmd, omega_cmd]'

tau_v = 0.1;      % Velocity time constant [s]
tau_omega = 0.1;  % Angular velocity time constant [s]

A_ext = [0, 0, 0, 1, 0;
         0, 0, 0, 0, 0;
         0, 0, 0, 0, 1;
         0, 0, 0, -1/tau_v, 0;
         0, 0, 0, 0, -1/tau_omega];

B_ext = [0, 0;
         0, 0;
         0, 0;
         1/tau_v, 0;
         0, 1/tau_omega];

C_ext = [1, 0, 0, 0, 0;
         0, 1, 0, 0, 0;
         0, 0, 1, 0, 0];

D_ext = zeros(3, 2);

%% Wheel velocity to body velocity conversion
function [v, omega] = wheelToBody(omega_L, omega_R, r, L)
    v = r * (omega_R + omega_L) / 2;
    omega = r * (omega_R - omega_L) / L;
end

%% Body velocity to wheel velocity conversion
function [omega_L, omega_R] = bodyToWheel(v, omega, r, L)
    omega_L = (v - omega * L / 2) / r;
    omega_R = (v + omega * L / 2) / r;
end

%% Velocity saturation
function [v_sat, omega_sat] = saturateVelocity(v, omega, v_max, omega_max)
    v_sat = max(min(v, v_max), -v_max);
    omega_sat = max(min(omega, omega_max), -omega_max);
end

Velocity Control Loop

flowchart TB
    subgraph TwistCmd["Twist Command (cmd_vel)"]
        V_D[/"v_cmd"/]
        W_D[/"ω_cmd"/]
    end

    subgraph Conversion["Inverse Kinematics"]
        CONV["ω_L = (v - ωL/2)/r<br/>ω_R = (v + ωL/2)/r"]
    end

    subgraph MotorControl["Motor PID Control"]
        subgraph Left["Left Wheel"]
            WL_D[/"ω_L_cmd"/]
            WL[/"ω_L_actual"/]
            ERR_L((+<br/>-))
            PID_L[PID<br/>Kp=1.0]
            PWM_L["PWM_L"]
        end
        subgraph Right["Right Wheel"]
            WR_D[/"ω_R_cmd"/]
            WR[/"ω_R_actual"/]
            ERR_R((+<br/>-))
            PID_R[PID<br/>Kp=1.0]
            PWM_R["PWM_R"]
        end
    end

    V_D --> CONV
    W_D --> CONV
    CONV --> WL_D
    CONV --> WR_D

    WL_D --> ERR_L
    WL --> ERR_L
    ERR_L --> PID_L
    PID_L --> PWM_L

    WR_D --> ERR_R
    WR --> ERR_R
    ERR_R --> PID_R
    PID_R --> PWM_R

    style TwistCmd fill:#e1f5fe
    style Conversion fill:#fff8e1
    style MotorControl fill:#e8f5e9

SLAM Architecture

flowchart TB
    subgraph SLAMSystem["SLAM System"]
        subgraph Frontend["Front-End"]
            SCAN[LiDAR<br/>Scan]
            MATCH[Scan<br/>Matching]
            ODOM[Odometry<br/>Integration]
        end

        subgraph Backend["Back-End"]
            GRAPH[Pose<br/>Graph]
            OPT[Graph<br/>Optimization]
            LOOP[Loop<br/>Closure]
        end

        subgraph Output["Outputs"]
            MAP[Occupancy<br/>Grid Map]
            POSE[Robot<br/>Pose]
        end
    end

    SCAN --> MATCH
    ODOM --> MATCH
    MATCH --> GRAPH
    GRAPH --> OPT
    LOOP --> OPT
    MATCH --> LOOP

    OPT --> MAP
    OPT --> POSE

    style Frontend fill:#e3f2fd
    style Backend fill:#fff3e0
    style Output fill:#e8f5e9
  • Localization: AMCL (Adaptive Monte Carlo Localization)
  • Global Planning: A, RRT, or Dijkstra path planning algorithms
  • Local Planning: DWA (Dynamic Window Approach) for obstacle avoidance
  • Costmaps: Static and dynamic obstacle representation
  • Recovery Behaviors: Stuck and obstacle recovery strategies

SLAM Capabilities

  • Gmapping: Grid-based SLAM using laser scan data
  • Cartographer: Google's real-time SLAM solution
  • Hector SLAM: Fast 2D SLAM without odometry requirement
  • RTAB-Map: 3D RGB-D SLAM (with camera)

Usage Examples

Basic Movement Control

# Move forward
linear_velocity = 0.2   # m/s
angular_velocity = 0.0  # rad/s

# Turn in place
linear_velocity = 0.0   # m/s
angular_velocity = 0.5  # rad/s

# Arc movement
linear_velocity = 0.15  # m/s
angular_velocity = 0.3  # rad/s
  1. Load World: Open turtlebot3/worlds/world.wbt
  2. Configure Controller: Set to simulink_control_app
  3. Open Model: Load state_space_modeling.slx in MATLAB
  4. Set Parameters: Configure PID gains and sensor settings
  5. Run Simulation: Execute with real-time data exchange

Common Applications

  1. Autonomous Navigation: Goal-based navigation with obstacle avoidance
  2. SLAM Mapping: Real-time environment mapping
  3. Follow-Me Robot: Person following using camera or LiDAR
  4. Multi-Robot Systems: Coordination of multiple TurtleBot3 units
  5. Educational Demos: Teaching robotics concepts

Educational Applications

Learning Objectives

The TurtleBot3 platform is excellent for teaching:

  • Mobile Robot Kinematics: Differential drive mathematics
  • Sensor Integration: LiDAR, IMU, and encoder fusion
  • Control Systems: PID control and feedback systems
  • Path Planning: A*, RRT, and potential field methods
  • SLAM Algorithms: Mapping and localization techniques
  • ROS Concepts: Node communication and system architecture

Laboratory Exercises

  1. Basic Movement: Implement teleoperation and waypoint navigation
  2. Sensor Processing: LiDAR data filtering and obstacle detection
  3. Mapping: Create maps using different SLAM algorithms
  4. Navigation: Implement autonomous navigation stack
  5. Multi-Robot: Coordinate multiple robots for formation control

Performance Characteristics

Motion Capabilities

  • Max Linear Speed: 0.22 m/s
  • Max Angular Speed: 2.84 rad/s
  • Minimum Turning Radius: Zero (turn in place)
  • Typical Operating Speed: 0.1-0.15 m/s for navigation

Sensor Performance

  • LiDAR Range: 0.12m - 3.5m
  • LiDAR Accuracy: ±3cm
  • Update Rate: 10-15 Hz (typical navigation frequency)
  • IMU Drift: <1°/hour (typical gyro drift)

References

Educational Purpose: The TurtleBot3 simulation provides a comprehensive platform for learning mobile robotics, SLAM, navigation, and control systems. Its integration with Simulink enables rapid prototyping of control algorithms and provides a bridge between theoretical concepts and practical implementation. The platform is widely used in robotics courses worldwide and serves as an excellent introduction to autonomous mobile robotics.
